Rage AL 27.5

available colors:

from 2.770,- €

27.5
``
wheel size
200
mm
rear travel
200
mm
front travel
3
years
warranty on frame

Aluminium Downhill bike in 27.5″

The new Rage has been completely redesigned, rolls on 650B wheels, and is available in three frame sizes (S, M, L). The geometry is inspired by the Rage Carbon and based on the experience of our World Cup team. A clean, sturdy and robust frame was the development goal for our engineering team. So we said “good bye” to some features of the previous Rage frame, such as the split seat tube design. The new design was inspired by the design of the popular Spindrift frame. In fact, some of Propain’s customers and Propain staff were fantasizing about a long travel version of the Spindrift for some time – a “Spindrift on Steroids”. Here it is, a downhill bike which focuses on reduced needs for maintenance whilst still delivering maximum performance for the high speeds and big hits that a park bike has to take.

Specs

We will help you on your way to your personal dream bike. Our options are only a preliminary recommendation, because your needs are as individual as you are. We have put together three pre-configured models for you. In our configuration tool, however, you can still adapt every single part of all models to your wishes. Have fun building your dream bike.

Start
Colors
Fork RockShox Boxxer RC 200 mm
Rear shock RockShox Super Deluxe Coil R 200 mm
Brake front Magura MT5 203 mm
Brake rear Magura MT5 203 mm
Saddle Sixpack Kamikaze
Seatpost Sixpack Menace
Wheels Propain ZTR FLOW S1
Cranks Truvativ Descendant DH 165 mm 36 Z
Rear derailleur SRAM GX DH (1×7)
Shifter SRAM GX DH (1×7)
Cassette SRAM PG 720 11/25 (1×7)
Handlebar Sixpack Millenium 785
Stem Sixpack Skywalker Direct Mount
Tires Schwalbe Magic Mary Addix
Weight 16,8 kg
Price € 2.770
Performance
Colors
Fork Formula Nero R 200 mm
Rear shock RockShox Super Deluxe Coil RC 200 mm
Brake front SRAM Code RSC 200 mm
Brake rear SRAM Code RSC 200 mm
Saddle Sixpack Kamikaze
Seatpost Sixpack Menace
Wheels Propain ZTR FLOW MK3
Cranks Truvativ Descendant DH 165 mm 36 Z
Rear derailleur SRAM GX DH (1×7)
Shifter SRAM GX DH (1×7)
Cassette SRAM PG 720 11/25 (1×7)
Handlebar Sixpack Millenium 785
Stem Sixpack Skywalker Direct Mount
Tires VEE Flow SNAP DH
Weight 16,3 kg
Price € 3.455
Highend
Colors
Fork Fox 40 Factory Grip2 203 mm
Rear shock Fox DHX2 Factory 200 mm
Brake front Magura MT7 203 mm
Brake rear Magura MT7 203 mm
Saddle Selle Italia XR
Seatpost Sixpack Menace
Wheels Reynolds Black Label Carbon DH
Cranks Sram X01 Carbon DH 165 mm 36 Z
Rear derailleur Sram X01 DH (1×7)
Shifter Sram X01 DH (1×7)
Cassette Sram XG795 10/24 (1×7)
Handlebar Sixpack Millenium Carbon 785
Stem Sixpack Skywalker Direct Mount
Tires Schwalbe Magic Mary Addix
Weight 15,7 kg
Price € 5.910

Frame size

The frame size is an essential part of the bike performance and above all of the riding fun. Select your required frame size from the table. If you stand between two sizes, then you only have to decide whether you like it playful or smooth running. For smooth running choose the larger frame size, for playful the smaller.

Technical Data

Shock length 230 mm
Shock travel 65 mm
Shock mount 8 x 25 mm
Rear wheel travel 200 mm
Bottom Bracket BSA 83 mm
Brake mount Postmount 180
Seatpost diameter 31,6 mm
Headset (S.H.I.S.) Top: IS42 / Bottom: IS52
Rear wheel axle 157 mm x 12 mm (X12)
Front deraillure none
Chainline 52 mm
Chainguide mount ISCG 05
Wheel size 650B
Maximum fork travel 203 mm
Frame weight 3,5 kg (Size M)

Geometry

Rage_Alu_2019_Geobild
SIZE S SIZE M SIZE L
Frame size (A) 420 mm / 16,5″ 420 mm / 16,5″ 420 mm / 16,5″
Wheelbase (M) 1.215 mm 1.240 mm 1.265 mm
Top tube length (G) 586 mm 611 mm 636 mm
Head tube length (D) 120 mm 120 mm 120 mm
Fork offset (B) 42 mm 42 mm 42 mm
Fork length (C) 580 mm 580 mm 580 mm
Chainstay length (L) 445 mm 445 mm 445 mm
Reach (E) 420 mm 445 mm 470 mm
Stack (F) 611 mm 611 mm 611 mm
Head angle (J) 63,5° 63,5° 63,5°
Seat angle effective (H) 74,5° 74,5° 74,5°
Seat angle actual (I) 64,5° 64,5° 64,5°
BB drop (K) 3 mm 3 mm 3 mm
