Rage Carbon 29 – Downhill Racebike in 29″

You want to ride the same equipment as the World Cup professionals? Then you are on the right track with the Rage Carbon 29. This is the machine of UK downhill racer Phil Atwill and his team mate, the current Austrian champion, David Trummer. Our World Cup-proven Rage Carbon has been further optimized and is even more uncompromising with its 29” wheels. Super fast and super light is just right to squeeze the last seconds out of your race run. With the award-winning Pro10 suspension system you can shred with unbelievable speed on the toughest downhill tracks on the planet. The ingenious Reach Adjustment System lets you adapt the bike perfectly to your size.

We will help you on your way to your personal dream bike. Our options are only a preliminary recommendation, because your needs are as individual as you are. We have put together three pre-configured models for you. In our configuration tool, however, you can still adapt every single part of all models to your wishes. Have fun building your dream bike.

Colors
ForkFormula Nero R 190 mm
Rear shockRock Shox Super Deluxe Coil RC 200 mm
Brake frontSram Code RSC 200 mm
Brake rearSram Code RSC 200 mm
SaddleSixpack Kamikaze
SeatpostSixpack Menace
WheelsPropain ZTR FLOW S1
CranksTruvativ Descendant DH 165 mm 36Z
Rear derailleurSram GX DH (1×7)
ShifterSram GX DH (1×7)
CassetteSram PG720 11/25 (1×7)
HandlebarSixpack Millenium 785
StemSixpack Skywalker Direct Mount
TiresSchwalbe Magic Mary Addix
Weight15,9 kg
Price€ 4.410
Colors
ForkFox 49 Factory Kashima 190 mm
Rear shockFox DHX Factory Kashima 200 mm
Brake frontMagura MT7 203 mm
Brake rearMagura MT7 203 mm
SaddleSelle Italia XR
SeatpostSixpack Menace
WheelsPropain ZTR FLOW MK3
CranksSram X01 DH DH 165 mm 36Z
Rear derailleurSram X01 DH (1×7)
ShifterSram X01 DH (1×7)
CassetteSram XG795 11/25 (1×7)
HandlebarSixpack Millenium Carbon 785
StemSixpack Skywalker Direct Mount
TiresSchwalbe Magic Mary Addix
Weight15,6 kg
Price€ 5.580

Frame size

We offer the Rage Carbon 29 only in frame size L/XL. It is aimed at rider from a height of approx. 1.77 m and taller. For all smaller riders we recommend 27.5″ wheels.

Shock length250 mm
Shock travel70 mm
Shock mount8 x 25 mm
Rear wheel travel200 mm
Bottom Bracket BSA83 mm
Brake mountPostmount 200
Seatpost diameter31,6 mm
Headset (S.H.I.S.)Tapered – Top: IS42 / Bottom: IS42
Rear wheel axle157 mm x 12 mm (X12)
Front deraillurenone
Chainline56,5 mm
Chainguide mountISCG 05
Wheel size29″
Maximum fork travel190 mm
Frame weight3,1 kg
Rage_CF

L

-10

L

0

L

+10

Frame size (A)420 mm / 16,5″420 mm / 16,5″420 mm / 16,5″
Wheelbase (M)1.262 mm1.272 mm1.282 mm
Head angle (J)63,0°63,0°63,0°
BB offset (K)16 mm16 mm16 mm
Seat angle – actual (H)60,5°60,5°60,5°
Seat angle – effective (I)73,5°73,5°73,5°
Head tube length (D)120 mm120 mm120 mm
Fork length (C)590 mm590 mm590 mm
Fork offset (B)48 mm48 mm48 mm
Chainstay length (L)459 mm459 mm459 mm
Top tube length (G)620 mm630 mm640 mm
Reach (E)437 mm447 mm457 mm
Stack (F)612 mm616 mm620 mm
Rage_CF

XL

-10

XL

0

XL

+10

Frame size (A)420 mm / 16,5″420 mm / 16,5″420 mm / 16,5″
Wheelbase (M)1.292 mm1.302 mm1.312 mm
Head angle (J)63,0°63,0°63,0°
BB offset (K)16 mm16 mm16 mm
Seat angle – actual (H)60,5°60,5°60,5°
Seat angle – effective (I)73,5°73,5°73,5°
Head tube length (D)120 mm120 mm120 mm
Fork length (C)590 mm590 mm590 mm
Fork offset (B)48 mm48 mm48 mm
Chainstay length (L)459 mm459 mm459 mm
Top tube length (G)650 mm660 mm670 mm
Reach (E)467 mm477 mm487 mm
Stack (F)612 mm616 mm620 mm
