The Rage is your key to success. With over 18 years of intensive development, close collaboration with our athletes, and countless World Cup races, the Rage has everything needed to conquer the toughest downhill tracks. Count on unwavering stability, reliable performance, and maximum speed to tackle any descent and win races.
The geometry of the Rage is fully designed for speed and stability, delivering maximum control in high-speed sections and technical, rough terrain. Thanks to the flip-chip and adjustable dropouts, the setup can be flexibly adapted to personal preferences.
The high-quality TPR chainstay protector makes the Rage particularly quiet. Additionally, cable mounts with a reduced diameter and firmly integrated cable clamps at the entry and exit points help to reduce noise levels.
With 200 mm of travel at the front and 215 mm at the rear, our Rage is ready for the toughest descents. The powerful rear triangle with plenty of progression makes the Rage the ultimate race bike and ensures maximum grip and comfort in every situation.
29” wheels are optimal for high speed and smooth handling, providing the best rollover capability, especially in technical
The mixed wheel setup, featuring a smaller 27.5” rear wheel, offers greater agility and maneuverability, while the large 29” front wheel provides excellent rollover capability and stability in rough and
We are excited to offer a limited Replica Edition of our World Cup team this time. This exclusive collection is available in a limited quantity and only with Mix wheelset. Experience the thrill of downhill racing and bring the PROPAIN Positive Vibe to your local bikepark.
Over many years, we have continuously developed our downhill bike with our World Cup team and roster of top athletes. The Rage has been rigorously tested on the toughest tracks and under the most extreme conditions. Thanks to continuous feedback and close collaboration with our riders, the performance has been consistently improved—with the clear goal of creating an uncompromising race bike.
Being the first bike in our portfolio, our RAGE embodies over 18 years of development. Starting with the launch of the first generation in 2010, we are now sending the fifth model off to the racetrack. From 3D-printed prototypes to production readiness, our bikes undergo an extensive development journey. Each component is tested for functionality and efficiency and continuously improved.
As with the previous models, the RAGE 3 R CF also focuses on maximum stability and uncompromising performance. Thanks to the revised carbon layup, the new RAGE is even more reliable and powerful, delivering the perfect balance of stiffness and flex.
The large downtube protector optimally shields the frame from rock impacts and other external forces. The newly developed chainstay and seatstay protectors, made from high-quality TPR plastic with air-filled nubs, have excellent damping properties and efficiently stop chain vibrations.
As one of the first manufacturers, we offer the Ochain Active Spider as a factory option in our online configurator. For those who prioritize maximum performance, it is an essential upgrade for downhill bikes.
All of our installed bearings are made from high-quality stainless steel and are protected by a double seal (PROPAIN Dirt-Shields). Wear on the bearings caused by moisture and dirt is therefore not an issue.
For a modern carbon frame that withstands ambitious riding for the long term, it’s not enough to use just any carbon material. Instead, it requires a blend of different carbon fibers and weaves, each with its own properties, to meet the demands. PROPAIN carbon frames are made from pre-preg carbon layers, which ensure an optimal resin content and significantly higher strength values. Each layer has specific properties and fulfills particular roles at different points of the frame. Based on requirements for stiffness, flexibility, impact resistance, weight, strength, and stress direction, various fibers and weaves are used.
We are 100% convinced that our PRO10 system remains the most powerful frame concept on the market. It is based on four pivot points and a floating shock that is activated by two counter-rotating links. The 215mm PRO10 rear end of the Rage 3 R CF, combined with the shock tuned to it, delivers a sensitive response and high progression. On the track, this translates to massive grip, plenty of support, and a feeling of never-ending suspension travel
Our progressive design of the rear suspension allows for maximum sensitivity at the beginning of the travel, enabling the suspension to absorb small bumps and trail chatter seamlessly.
The responsiveness of the rear end, combined with the defined lateral stiffness (compliance) of all PRO10 rear ends, enables precise line-holding even through rough terrain.
With an anti-squat calibrated to each model at just over 100%, we achieve an extremely stable pedaling platform across all bikes, effectively preventing bobbing during strong acceleration.
The wheel rise curve begins directed backward to minimize resistance when avoiding obstacles. At the same time, the wheel rise curve is optimized to ensure no noticeable pedal kickback.
The forces acting during braking can compress the rear suspension and counteract the weight shift caused by braking. The PRO10ROsuspension system effectively utilizes this effect to ensure controlled braking while maintaining optimal suspension performance.
The shock is connected via two links, resulting in virtually no lateral forces acting on the shock. This maximizes the effectiveness and longevity of the shock.
The force transfer from the rear end to the main frame is very uniform due to the floating system, allowing for an overall lightweight frame construction.
The large stainless steel bearings are protected by an additional seal (Propain Dirt-Shields) and guarantee an extremely long lifespan. The positioning of the bearings ensures very low forces acting on them, further reducing maintenance intervals.
The positioning of the shock contributes to a very low and central center of gravity, significantly enhancing the bikes' handling.
18 years ago, the Rage, along with the PRO10 suspension system, laid the foundation for PROPAIN. Initially, when company founder Robert Krauss wanted to develop the perfect downhill bike for himself, it was meant to be a bike for him and his friends. He created a list of 10 requirements that the suspension system needed to meet. The result remains the heart and success formula of PROPAIN bikes to this day.
The size of the frame plays an important role in the bike’s performance and, above all, in its enjoyment. Select the frame size you need from the table. If you are between two sizes, then you only have to decide whether you like it playful or smooth. For smooth riding, choose the larger frame size, for playful riding, choose the smaller frame size.
| 160cm 5'3″ | 170cm 5'7″ | 180cm 5'11“ | 190cm 6'3″ | 200cm 6'7″ | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| M |
|
||||||||||
| L |
|
||||||||||
| XL |
|
||||||||||
|
|
|||||||||||
| Shock length | 225mm |
| Shock travel | 75mm |
| Shock bushings | 8 x 30 mm / Trunnion |
| Travel (Frame) | 215mm |
| Max. Travel (Fork) | 200mm |
| Bottom bracket | BSA 83 |
| Brake mount (Frame) | Postmount 200 |
| Seatpost diameter | 31.6mm |
| Seatclamp diameter | 36.4mm |
| Headset (S.H.I.S.) | Top: ZS56 / Bottom: ZS56 |
| Rear wheel axle | 157mm x 12mm |
| Chainline Offset | 6mm offset |
| Chainline | 56.5mm |
| Chainguide mount | ISCG 05 |
| Derailleur hanger | PROPAIN 2-pos. derailleur hanger |
| Wheel size | 29″ / 29″ |
| Max. system weight | 120kg |
Typical race genes: a long reach and a flat steering angle of 63° ensure speed and maximum stability on all downhill routes. In combination with the adjustable chainstay, we give our downhiller additional agility and maneuverability to always find the best line in technical passages.
| Size M | Size L | Size XL | |
|---|---|---|---|
| Frame height (A) | 420mm | 440mm | 440mm |
| Fork offset (B) | 46mm | 46mm | 46mm |
| Fork length (C) | 602mm | 602mm | 602mm |
| Head tube length (D) | 100mm | 110mm | 110mm |
| Reach (E) | 440mm | 465mm | 495mm |
| Stack (F) | 629mm | 638mm | 638mm |
| Head angle (G) | 63° | 63° | 63° |
| Seat angle – real (H) | 69° | 69° | 69° |
| Seat angle – effective (I) | 79° | 79° | 79° |
| Top tube length (J) | 562mm | 589mm | 619mm |
| BB offset (K) | 21mm | 21mm | 21mm |
| Short Chainstay length (L) | 445mm | 445mm | 445mm |
| Long Chainstay length (L) | 460mm | 460mm | 460mm |
| Short Wheelbase (M) | 1,246mm | 1,275mm | 1,305mm |
| Long Wheelbase (M) | 1,261mm | 1,290mm | 1,320mm |
| Size M | Size L | Size XL | |
|---|---|---|---|
| Frame height (A) | 420mm | 440mm | 440mm |
| Fork offset (B) | 46mm | 46mm | 46mm |
| Fork length (C) | 602mm | 602mm | 602mm |
| Head tube length (D) | 100mm | 110mm | 110mm |
| Reach (E) | 440mm | 465mm | 495mm |
| Stack (F) | 629mm | 638mm | 638mm |
| Head angle (G) | 63° | 63° | 63° |
| Seat angle – real (H) | 69° | 69° | 69° |
| Seat angle – effective (I) | 79° | 79° | 79° |
| Top tube length (J) | 562mm | 589mm | 619mm |
| BB offset (K) | 3mm | 3mm | 3mm |
| Short Chainstay length (L) | 445mm | 445mm | 445mm |
| Long Chainstay length (L) | 460mm | 460mm | 460mm |
| Short Wheelbase (M) | 1,246mm | 1,275mm | 1,305mm |
| Long Wheelbase (M) | 1,261mm | 1,290mm | 1,320mm |
You have questions about your next bike?
Our customer service team is here to help and support you!
Book an appointment now for a consultation on the phone or in our showroom. Of course, you can also contact us via our chat on our website or by email. We look forward to hearing from you!
Ursprünglicher Preis war: 109,20 €83,19 €Aktueller Preis ist: 83,19 €.
plus shipping
33,61 €
plus shipping
33,61 €
plus shipping
Ursprünglicher Preis war: 75,59 €63,03 €Aktueller Preis ist: 63,03 €.
plus shipping
Become part of the PROPAIN community and receive all updates about our products, athletes and insights with our newsletter.
© 2024 Propain Bicycles GmbH
| Fork | Öhlins RXF DH 38 200 mm |
|---|---|
| Shock | Öhlins TTX 22 Coil |
| Brakes | Shimano Saint 203 mm / 203 mm |
| Wheels | NEWMEN Beskar 30 DH |
| Drive train unit | Shimano Saint (1x10) |
| Trigger | Shimano Saint SL-M825 |
| Derailleur | Shimano Saint RD-M820 |
| Cassette | Shimano Saint CS-6700 |
| Crank | Shimano Saint M825 |
| Handlebar | DMR ODUB35 |
| Grips | DMR Deathgrip |
| Headset & Stem | Sixpack Millenium DRM 45mm |
| Seatpost | Sixpack Kamikaze |
| Saddle | DMR Stage 2 |
| Tires | Schwalbe |
The Factory package not only impresses with its striking appearance, but also plays in the top league when it comes to performance. The Fox 40 Factory in combination with the DHX2 Coil SLS come in the well-known Kashima design and guarantee ultimate performance. Complemented by the high-quality SRAM XO 7-speed gears and extremely robust FR 1500 DH wheels from DT Swiss, this kit is absolutely high-end.
| Fork | Fox 40 Factory GripX2 200mm |
|---|---|
| Shock | Fox DHX2 Factory |
| Brakes | Magura MT7 Performance 220mm / 203 mm |
| Wheels | DT Swiss FR 1500 DH |
| Drive train unit | Ochain Active Spider SRAM X01 DH (1x7) |
| Grips | Ergon GDH Team |
| Handlebar | OneUp Carbon |
| Headset & Stem | Sixpack Millenium DRM |
| Seatpost | Sixpack Kamikaze |
| Saddle | Ergon SM Downhill Comp |
| Tires | Schwalbe Magic Mary / Big Betty Super DH Addix Soft |
The perfect choice for outstanding performance, maximum confidence and a cool look. The Öhlins Chassis guarantees an incomparable driving experience on every track and provides that extra portion of racing mode. The Shimano Saint brakes offer you first-class braking power, while thehe The drive of the same name ensures reliable and precise switching behavior.
| Fork | Öhlins RXF DH 38 200 mm |
|---|---|
| Shock | Öhlins TTX 22 Coil |
| Brakes | Shimano Saint 203 mm / 203 mm |
| Wheels | NEWMEN Beskar 30 DH |
| Drive train unit | Shimano Saint (1x10) |
| Grips | Ergon GDH Team |
| Handlebar | OneUp Carbon |
| Headset & Stem | Sixpack Millenium DRM |
| Seatpost | Sixpack Kamikaze |
| Saddle | Ergon SM Downhill Comp |
| Tires | Continental Kryptotal FR/RE 2.4 DH |
Our “Heavy-hitter“-Spec – the name says it all. With the RockShox Boxxer Ultimate in "Electric Red“ and the Vivid Coil Ultimate DH, no jump is too far and no drop too high. You get the perfect balance between performance and comfort. Also at the start: the NEMEN Beskar 30 DH for demanding terrain and the SRAM GX 7-speed drive.
| Fork | RockShox Boxxer Ultimate 200 mm |
|---|---|
| Shock | RockShox Vivid Coil Ultimate DH |
| Brakes | SRAM Code RSC 220 mm / 200 mm |
| Wheels | NEWMEN Beskar 30 DH |
| Drive train unit | SRAM GX DH (1x7) |
| Grips | Ergon GDH Team |
| Handlebar | Sixpack Millenium 805 |
| Headset & Stem | Sixpack Millenium DRM |
| Seatpost | Sixpack Kamikaze |
| Saddle | Ergon SM Downhill Comp |
| Tires | Schwalbe Magic Mary / Big Betty Super DH Addix Soft |
A solid basic equipment that will never let you down on your days in the bike park and is absolutely “ready to shred“ Fun guaranteed with the RockShoxchassis, the powerful DB 8 brakes and the reliable GX 7-speed drive from SRAM. There is also the NEWMEN Performance 30 DH wheels for proper stability.
| Fork | RockShox Boxxer 200 mm |
|---|---|
| Shock | RockShox Vivid Coil DH |
| Brakes | SRAM DB8 220 mm / 200 mm |
| Wheels | NEWMEN Performance 30 DH |
| Drive train unit | SRAM GX DH (1x7) |
| Grips | Sixpack S-Trix |
| Handlebar | Sixpack Millenium 805 |
| Headset & Stem | Sixpack Millenium DRM |
| Seatpost | Sixpack Kamikaze |
| Saddle | Sixpack Kamikaze |
| Tires | Continental Kryptotal FR/RE 2.4 DH |
