Yuma 3

24″/26″ Fully
8 – 13 Years
130 – 160 cm

USD $2,299.00

Out of stock

Our kids bikes will be available for order end of July 2023.
Sign up now for our newsletter and be one of the first to be notified!

Grow with it

This is it, your first proper mountain bike. With 140mm travel and a great spec, it’s the perfect playmate for your next adventure. Whether on the pump track, a bike park session or in the woods behind the house. Grab your Yuma 3 and have a great time you’ll never forget.

The Yuma 3 is recommended for body sizes between 130 cm and 160 cm (8 to 13 years).

Our kids bikes will be available for order end of October 2023.
Sign up now for our newsletter and be one of the first to be notified!

USD $2,299.00

Out of stock

It's playtime

The first day of summer vacation – you and your buddy grab your bikes and go. Build kickers, explore the woods behind your house and just have fun. The whole day on the bike. That’s what the Yuma 3 is made for.

Ready for action

Bike park approved – The Yuma 3 is classified category 5 and therefore does not fear rough terrain and big jumps. Robustly built to withstand even the hardest rides!

Youngsters wanted

From 1.25m it’s good to go. Thanks to the reduced standover height the Yuma 3 is easy to handle. The kinematics are specially designed so that the suspension works well even with light weight riders.

Grow with it

Everyone grows up and progresses and so does the Yuma 3, it can grow with you. Our “rookie launcher” comes with 24″ wheels. With a flip chip, the bike can be converted to 26″ wheels in the blink of an eye. So, the bike grows with you and lasts a long time.

The Grown-Up Kit on 26″ wheels can be purchased in our web shop and is not included with the bike.

Specs

Components specially selected for the needs of kids round off the Yuma 3 as a proper mountain bike for young and ambitious riders. Make the world as you like it: As with all PROPAIN bikes, you can freely combine the frame color with decals and grips.

Price
2.299 €

Fork

RockShox Reba
140 mm

Shock

RockShox Deluxe Select R 140mm

Brakes

SRAM Guide T 200mm / 180mm

Wheels

Newmen Evolution X.A.25

Frequently Asked Questions

Frequently Asked Questions – bitte leer lassen

Optimized for kids down to the last detail

Comfort and grip

The suspension system of the Yuma 3 is ideally designed for kids and their needs. It is very light and at the same time provides the optimum sensitivity and progression. In addition, it is easy to maintain and simple to handle.

Everything on board

A tool, snacks or spare tube – a practical storage bag for all the important little things on the next trail ride.

Performance

The Yuma 3 is equipped for any challenge thanks to the superior shifting performance of the 1×11 SRAM GX drivetrain. Even steep ramps can be climbed easily. The frame is protected by our chainstay protector for those times when you really hit it.

Highlights

The Yuma 3 may be small, but it doesn’t lag behind the big sibling bikes and therefore comes with many thoughtful details.

Always stay hydratedFrames have space for bottles up to 0.5l. So even on longer rides you will have plenty of water. — Always stay hydrated
Frames have space for bottles up to 0.5l. So even on longer rides you will have plenty of water.

Take it easyThe lightweight aluminium frame and balanced geometry give the young shredders confidence and stability. The slack head angle and the low bottom bracket ensure safe handling even in rough terrain. — Take it easy
The lightweight aluminium frame and balanced geometry give the young shredders confidence and stability. The slack head angle and the low bottom bracket ensure safe handling even in rough terrain.

POV1st Ride components such as handlebars, stem and grips are designed specifically for the demands of kids. The SRAM Guide T offers a lot of brake power and can be well adjusted thanks to grip-width adjustment. — POV
1st Ride components such as handlebars, stem and grips are designed specifically for the demands of kids. The SRAM Guide T offers a lot of brake power and can be well adjusted thanks to grip-width adjustment.

Up and DownThe optimal combination of the top tube length with the steep seat angle allows the youngsters an upright pedal position and a balanced weight distribution when going downhill. — Up and Down
The optimal combination of the top tube length with the steep seat angle allows the youngsters an upright pedal position and a balanced weight distribution when going downhill.

Internal cable routingThe internal cable routing is now standard on modern bikes, so we have also added it to the new Yuma. The cables now run inside the frame and provide a clean look and are safe from snags. — Internal cable routing
The internal cable routing is now standard on modern bikes, so we have also added it to the new Yuma. The cables now run inside the frame and provide a clean look and are safe from snags.

Bitte leer lassen

Frame sizes

14″: 90-110 cm / 16″: 95-115 cm / 20″: 110-145 cm / 24″: 130-145 cm / 26″: 145-160 cm

	90 cm	100 cm	110 cm	120 cm	130 cm	140 cm	150 cm
14″
16″
20″
24″
26″
	Smoothly running Well-balanced Playful

Technical Data

Shock length	185 mm
Shock travel	55 mm
Shock bushings	Top: Trunnion / Bottom: 8 x 35 mm
Travel (Frame)	140 mm
Max. Travel (Fork)	150 mm
Bottom Bracket BSA	73 mm
Brake mount (Frame)	Postmount 160
Seatpost diameter	31,6 mm
max. Seatpost insert length	300 mm
Headset (S.H.I.S.)	Top: IS42 / Bottom: IS52
Rear wheel axle	148 mm x 12 mm
Chainline Offset	3 mm Offset
Chainline	52 mm (Boost)
Chainguide mount	ISCG 05
Derailleur hanger	PROPAIN Yuma Derailleur hanger
Wheel sizes	24″ / 26″
Frame weight	2,7 kg
Max. rider weight	80 kg

Geometry

* Measured 100 mm from center of bottom bracket
	24″	26″
Frame height (A)	320 mm	320 mm
Fork offset (B)	42 mm	42 mm
Fork length (C)	520 mm	520 mm
Head tube length (D)	95 mm	95 mm
Reach (E)	380 mm	380 mm
Stack (F)	545 mm	545 mm
Head angle (G)	65°	65°
Seat angle – real (H)	72.5°	72.5°
Seat angle – effective (I)	75°	75°
Top tube length (J)	526 mm	526 mm
BB offset (K)	3 mm	3 mm
Chainstay length (L)	420 mm	432 mm
Wheelbase (M)	1,099 mm	1,111 mm
Standover height (N)*	662 mm	687 mm

Downloads

FAQ

Frequently Asked Questions

Frequently Asked Questions – bitte leer lassen

Is it possible to order the Yuma directly as a 26″ build?

Unfortunately not. For production and process-related reasons, we only offer the 26″ upgrade kit for additional purchase.

Which dropouts are necessary for a conversion from 24″ to 26″?

Due to the flip chip on the Yuma, no additional dropouts are necessary. The same dropouts can simply be used for the conversion from 24″ to 26″.

Which body size is recommended for the Yuma?

We recommend the Yuma in 24″ for a body height of 1.25 m or more. The full size chart can be found on our website.

Is the Yuma compatible with a dropper seat post?

The Yuma has cable channels prepared inside the frame for the cable routing of a dropper seat post. Therefore, dropper seat posts can be retrofitted if required.

Do you also offer other components thar are not listed in the configurator?

We offer the Yuma in one configuration. Decals, grips and the head tube badge can be selected and configured as desired.

Which bottle size fits in the frame?

Attaching drinking bottles up to 0.5 l is no problem.

What does the delivery include?

The bike comes with all the instructions and manuals you need.

What kind of terrain is the Yuma suitable for?

The Yuma is classified in category 5 and thus approved for the bike park. Therefore, the Yuma can be used from a simple ice cream ride up to action in the bike park.

What is the maximum tire width that fits the bike?

Tires up to a width of 2.4 can be fitted to the Yuma.
