Spindrift 5 AL Park

from USD $3,199.00

Payment in installment
possible with Affirm

Buy now

Freeride aint’t dead

Full Park mode on! With our Park Edition and the 200mm double crown fork, you’re ready for the wildest descents. Whether it’s high drops or massive jumps, tricks and style are the order of the day. With the agile mixed setup and 7-speed DH drivetrain, there are no limits to your creativity.

Double Crown – Double Fun

from USD $3,199.00

plus shipping
ready to ship approx. 10-15 business days *

Ample Reserve

200mm of front suspension travel for the biggest jumps and massive drops

Maneuverability and Agility

Playful and responsive handling thanks to a short geometry and a 27.5” rear wheel

Grip and Support

Freeride-tuned PRO10 system for smooth responsiveness and ample reserve

Full Downhill-Performance

With a 200 mm double crown fork, a 7-speed DH drivetrain, and a mix only setup, our Spindrift 5 AL Park is fully geared for DH action.

Short Geometry for Maximum Agility

The short frame geometry of the aluminum version makes the bike very playful and nimble. Its lively handling makes spins and flips a regular occurrence with the Spindrift 5 AL. Grab it, spin it, flip it.

Slack Head Angle for Better Downhill Performance

The slack head angle of 63.5° provides optimal handling on steep descents and ensures maximum control at high speeds, in technical blockages, and challenging terrain.

Customize yours now

Through our extensive online configurator, the character of all our bikes can be influenced to varying degrees. The Spindrift 5 AL Park offers you an especially wide range of options.
Make the Spindrift 5 AL Park what you need it to be.

Wheel Sizes

Versatility with Mixed Wheels

M L XL
The mixed wheel setup, featuring a smaller 27.5” rear wheel, offers greater agility and maneuverability, while the large 29” front wheel provides excellent rollover capability and stability in rough and steep terrain.

Build Kits

We’re here to help you create your dream bike. Our four build kits are clear recommendations based on how we would set up our own bikes. For every riding style and budget, we provide a thoughtfully designed equipment concept that gets you “ready to ride” right out of the box. At PROPAIN, we always prioritize customization, so you can still fulfill every individual wish through our configurator.

Factory

$ 5,989
  • Fork:
    Fox 40 Factory GripX2 200 mm
  • Rear shock:
    Fox DHX2 Coil SLS
  • Drive train:
    SRAM XO 7 Speed
  • Brake:
    Magura MT7 Performance 220 mm / 203 mm
  • Seatpost:
    Sixpack Kamikaze
  • Wheelset:
    DT Swiss FR 1500 DH

Ultimate

$ 4,999
  • Fork:
    RockShox Boxxer Ultimate 200 mm Electric Red
  • Rear shock:
    RockShox Vivid Air Ultimate
  • Drive train:
    SRAM GX 7 Speed
  • Brake:
    SRAM Code RSC 220 mm / 200mm
  • Seatpost:
    Sixpack Kamikaze
  • Wheelset:
    DT Swiss FR 1500 DH

Swedish Gold

$ 4,589
  • Fork:
    Öhlins RXF 38 200 mm
  • Rear shock:
    Öhlins TTX 22 Coil
  • Drive train:
    SRAM GX 7 Speed
  • Brake:
    Shimano Saint 203 mm / 203 mm
  • Seatpost:
    Sixpack Kamikaze
  • Wheelset:
    NEWMEN Performance 30 DH

Base

$ 3,199
  • Fork:
    RockShox Boxxer 200 mm
  • Rear shock:
    RockShox Vivid Coil Select R
  • Drive train:
    SRAM GX 7 Speed
  • Brake:
    SRAM DB8 220 mm / 200 mm
  • Seatpost:
    Sixpack Kamikaze
  • Wheelset:
    NEWMEN Performance 30 DH

Silence is Fast

A quiet bike changes your perception on the trail and provides a tremendous sense of security. The high-quality TPR chainstay protectors, combined with cable integration and optimized cable routing, make the Spindrift 5 AL Park exceptionally quiet.

Cable Ports and Internal Cable Routing

Securely screwed and internally clamped cable ports with seals to protect against dust and water ensure optimal cable management and also minimize noise. For the Spindrift 5 AL Park , we continue to use classic internal routing through the frame.

PRO10 and Downtube Protection

Extremely agile and balanced thanks to PRO10. Whether using a coil or air shock, this technology provides excellent anti-squat characteristics, ensuring optimal traction regardless of the setup. Our specially designed downtube protection shields the frame from external impacts and damage.

Freeride aint’t dead

Through our extensive online configurator, the character of all our bikes can be influenced to varying degrees. The Spindrift 5 AL Park offers you an especially wide range of options.
Make the Spindrift 5 AL Park what you need it to be.

High-Quality Stainless Steel Bearings

All our installed ball bearings are made from high-quality stainless steel and are protected with double seals (PROPAIN Dirt-Shields). This makes the Spindrift 5 AL Park extremely durable and resistant.

Blend Alloy

The frame consists of at least three different alloys, which together create the optimum combination of stiffness, strength and weight. Frame parts such as rockers and axles are made of 7075 T6 aluminium, which has a very high strength. For the tubes of the frame, a more fatigue-resistant 6066 T6 aluminium is used. In addition, the milled and forged parts are made of 6061 T6 aluminium. Blend Alloy thus represents our special and unique manufacturing process and ensures the optimum performance of the lightweight frames.
Bitte leer lassen
The size of the frame plays an important role in the bike’s performance and, above all, in its enjoyment. Select the frame size you need from the table. If you are between two sizes, then you only have to decide whether you like it playful or smooth. For smooth riding, choose the larger frame size, for playful riding, choose the smaller frame size.
M: 168-182 cm / L: 178-192 cm / XL: 188-202 cm
150 cm 4’11” 160 cm 5’3″ 170 cm 5’7″ 180 cm 5’11” 190 cm 6’3″ 200 cm 6’7″
M
L
XL
Smoothly running
Well-balanced
Playful
The adjustable seatpost is probably one of the most ingenious inventions of recent years. In order to function optimally on the trail, the proper seatpost travel is very important. The following chart shows the recommended minimum inseam for the corresponding frame size. Please keep in mind that this is only a recommendation, as the respective sitting position depends very much on personal habits and preferences.
* Innenbeinlänge in cm
Spindrift 5 AL S M L XL
OneUp Dropper V3 120 73 75 77 79
OneUp Dropper V3 150 75 75 77 79
OneUp Dropper V3 180 78,5 78,5 79,5 79,5
OneUp Dropper V3 210 82 82 83 83
Bikeyoke Revive 3 125 73 75 77 79
Bikeyoke Revive 3 160 80 80 81 82,5
Bikeyoke Revive 3 185 85 85 86 86
Bikeyoke Revive 3 213 91,5 91,5 92,5 92,5
Fox Transfer Factory MY25 120 73 75 77 79
Fox Transfer Factory MY25 150 78,5 78,5 79,5 81,5
Fox Transfer Factory MY25 180 84 84 85 85
Fox Transfer Factory MY25 210 89,5 89,5 90,5 90,5
RockShox Reverb AXS 125 75,5 77,5 79,5 81,5
RockShox Reverb AXS 150 80,5 80,5 82 84
RockShox Reverb AXS 170 84,5 84,5 85,5 86
Shock length 230 mm
Shock travel 65 mm
Shock bushings Top: 8 x 20 mm / Bottom: 8 x 30 mm
Travel (Frame) 180 mm
Max. Travel (Fork) 200 mm
Bottom bracket BSA 73 mm
Brake mount (Frame) Postmount 180
Seatpost diameter 31.6 mm
Seat clamp diameter 34.9 mm
max. Seatpost insert length
29″ & Mix 27,5″
Frame size S 200 mm
Frame size M 215 mm 220 mm
Frame size L 220 mm 230 mm
Frame size XL 250 mm
Headset (S.H.I.S) Top: ZS49 / Bottom: ZS56
Rear wheel axle 148 mm x 12 mm
Chainguide mount ISCG 05
Derailleur hanger SRAM UDH
Wheel size 29″ / Mix / 27,5″
Max. system weight 120 kg
The Spindrift 5 AL also features our proven PRO10 System. This enhances your descents with increased agility and offers better balance on your rides. The anti-squat behavior provides improved traction and ground contact. With a slack head angle of 63.5° and an effective seat angle of 76.4°, this freerider tackles the steepest climbs with ease.

180 mm Fork

* Measured 200 mm from cener of bottom bracket
Size S M L M L XL M L XL
Wheelsize 27,5 27,5 27,5 Mix Mix Mix 29 29 29
Frame height (A) 420 mm 440 mm 460 mm 440 mm 460 mm 480 mm 440 mm 460 mm 480 mm
Fork offset (B) 38 mm 38 mm 38 mm 44 mm 44 mm 44 mm 44 mm 44 mm 44 mm
Fork length (C) 577 mm 577 mm 577 mm 596 mm 596 mm 596 mm 596 mm 596 mm 596 mm
Head tube length (D) 100 mm 110 mm 120 mm 100 mm 110 mm 125 mm 100 mm 110 mm 125 mm
Reach (E) 430 mm 455 mm 478 mm 455 mm 480 mm 505 mm 455 mm 480 mm 505 mm
Stack (F) 605 mm 614 mm 623 mm 636 mm 644 mm 658 mm 636 mm 644 mm 658 mm
Head angle (G) 63,9° 63,9° 63,9° 63,9° 63,9° 63,9° 63,9° 63,9° 63,9°
Seat angle – real (H) 76,4° 76,4° 76,4° 75,2° 74,9° 74,9° 75,2° 74,9° 74,9°
Seat angle – effective (I) 78,4° 78,4° 78,4° 78,4° 78,7° 78,6° 78,4° 78,7° 78,6°
Top tube length (J) 553 mm 580 mm 607 mm 585 mm 612 mm 641 mm 585 mm 612 mm 641 mm
BB offset FW/RW (K) R7 / F7 mm R7 / F7 mm R7 / F7 mm R7 / F20 mm R7 / F20 mm R7 / F20 mm R20 / F20 mm R20 / F20 mm R20 / F20 mm
Chainstay length (L) 435 mm 435 mm 435 mm 435 mm 435 mm 435 mm 445 mm 445 mm 445 mm
Wheelbase (M) 1.196 mm 1.226 mm 1.255 mm 1.234 mm 1.264 mm 1.295 mm 1.244 mm 1.274 mm 1.305 mm
Standover height (N)* 816 mm 814 mm 814 mm 829 mm 826 mm 829 mm 829 mm 826 mm 829 mm
BB height 342 mm 342 mm 342 mm 349 mm 349 mm 349 mm 349 mm 349 mm 349 mm

200 mm Fork

* Measured 200 mm from center of bottom bracket
Size M Size L Size XL
Wheelsize Mix
only
Mix
only
Mix
only
Frame height (A) 440 mm 460 mm 480 mm
Fork offset (B) 52 mm 52 mm 52 mm
Fork length (C) 609 mm 609 mm 609 mm
Head tube length (D) 100 mm 110 mm 125 mm
Reach (E) 450 mm 475 mm 500 mm
Stack (F) 639 mm 647 mm 661 mm
Head angle (G) 63,5° 63,5° 63,5°
Seat angle – real (H) 74,8° 74,5° 74,5°
Seat angle – effective (I) 78° 78,3° 78,2°
Top tube length (J) 582 mm 609 mm 638 mm
BB offset FW/RW (K) R23 / F23 mm R23 / F23 mm R23 / F23 mm
Chainstay length (L) 435 mm 435 mm 435 mm
Wheelbase (M) 1.248 mm 1.278 mm 1.309 mm
Standover height (N)* 832 mm 829 mm 832 mm
BB height 352 mm 352 mm 352 mm

You have questions about your next bike?
Our customer service team is here to help and support you!

Book an appointment now for a consultation on the phone or in our showroom. Of course, you can also contact us via our chat on our website or by email. We look forward to hearing from you!

Freeride aint’t dead

Factory

Our Factory package ranks at the top both visually and technically. The dual crown fork in premoim Kashima finish and the Fox DHX2 Coil SLS bring ultimate performance to the park. Combined with a SRAM X0 7-Speed drivetrain, our high-end package is complete.

Fork Fox Float 40 Factory 203mm
Shock Fox DHX2 Factory Coil
Brakes Magura MT7 Performance 220 mm / 203 mm
Wheels DT Swiss FR 1500 DH
Drive train unit SRAM X01 DH (1x7)
Trigger SRAM X01 DH
Derailleur SRAM X01 DH
Cassette SRAM XG-795 DH
Crank SRAM X01 Eagle 175mm 32t
Handlebar OneUp Carbon
Stem Sixpack Millenium DRM
Seatpost Sixpack Kamikaze Aluminium
Saddle Sixpack Kamikaze
Tires Schwalbe Magic Mary / Big Betty
Chainguide Sixpack Millenium

Ultimate

Our “Heavy-Hitter”  spec. With the RockShox Boxxer Ultimate in brand-new “Electric Red” and the Vivid Air Ultimate shock, you´ll  have the perfect balance of control and speed. Also included: full braking power with he SRAM Code RSC and a precise GX 7-Speed drivetrain.

Fork RockShox Boxxer Ultimate 200 mm
Shock RockShox Vivid Air Ultimate
Brakes SRAM Code RSC 220 mm / 200 mm
Wheels DT Swiss FR 1500 DH
Drive train unit SRAM GX DH (1x7)
Trigger SRAM X01 DH
Derailleur SRAM GX DH
Cassette SRAM PG-720 DH
Crank Truvative Descendant 170 mm 32t
Handlebar OneUp Carbon
Stem Sixpack Millenium DRM
Seatpost Sixpack Kamikaze Aluminium
Saddle Sixpack Kamikaze
Tires Continental Kryptotal FR/RE 2.4
Chainguide Sixpack Millenium

Swedish Gold

The perfect choice for outstanding performance, maximum confidence, and a cool look. The Öhlins RXF 38 dual drown fork and the Öhlins TTX 22 shock guarantee an unparalleled riding experience precise and reliable shifting.

Fork Öhlins RXF DH 38 200 mm
Shock Öhlins TTX 22 Coil
Brakes Shimano Saint 203 mm / 203 mm
Wheels NEWMEN Performance 30 DH
Drive train unit SRAM GX DH (1x7)
Trigger SRAM X01 DH
Derailleur SRAM GX DH
Cassette SRAM PG-720 DH
Crank Truvative Descendant 170 mm 32t
Handlebar Sixpack Millenium 805
Stem Sixpack Millenium DRM
Seatpost Sixpack Kamikaze Aluminium
Saddle Sixpack Kamikaze
Tires Continental Kryptotal FR/RE 2.4 DH
Chainguide Sixpack Millenium

Base

A solid base setup, perfect for being “ready to shred” in the bike park. Fun is guaranteed by RockShox with the Boxxer Base dual crown fork and the Vivid Coil Select R. The GX 7-Speed drivetrain combined with the DB8 brakes, both from SRAM, complete the package.

Fork RockShox Boxxer 200mm
Shock RockShox Vivid Coil Select R
Brakes SRAM DB8 220 mm / 200 mm
Wheels NEWMEN Performance 30 DH
Drive train unit SRAM GX 7 Speed (1x7)
Trigger SRAM GX DH
Derailleur SRAM GX DH
Cassette SRAM PG-720 DH
Crank Truvative Descendant 170 mm 32t
Handlebar Sixpack Millenium 805
Stem Sixpack Millenium DRM
Seatpost Sixpack Kamikaze Aluminium
Saddle Sixpack Kamikaze
Tires Schwalbe Magic Mary / Big Betty DH
Chainguide Sixpack Millenium
