SPINDRIFT 5 AL

from USD $2,999.00

Payment in installment
possible with Affirm

Buy now

FREERIDE AIN’T DEAD

Challenging trails, big jump lines, or high drops—one thing is guaranteed with our Spindrift 5 AL: fun and going wild! Feel the versatility of this purebred freerider and let your creativity run wild. With its robust aluminum frame, no drop is too high, and no jump is too far. It also handles uphill rides, so everything is prepared for your after-work sessions on your home trails, where things can get intense.

Robust, playful, versatile

from USD $2,999.00

plus shipping

ready to ship approx. 4 weeks *

Reliability and Durability

Robust and long-lasting due to the use of Blend Alloy

Maneuverability and Agility

Playful and responsive handling thanks to a short geometry

Grip and Support

Freeride-tuned PRO10 System for excellent responsiveness and plenty of reserve

Play

Durable and robust thanks to Blend Alloy

By using various alloys, the Spindrift 5 AL is made from at least three different metals. This manufacturing process makes the material highly resistant to fatigue, providing the frame with exceptionally high strength and robustness.

Short Geometry for Maximum Agility

The short frame geometry of the aluminum version makes the bike very playful and nimble. Its lively handling makes spins and flips a regular occurrence with the Spindrift 5 AL. Grab it, spin it, flip it.

Slack Head Angle for Better Downhill Performance

The slack head angle of 63.9° provides optimal handling on steep descents and ensures maximum control at high speeds, in technical blockages, and challenging terrain.

Customize yours now

Through our extensive online configurator, the character of all our bikes can be influenced to varying degrees. The Spindrift 5 AL offers you an especially wide range of options.
Make the Spindrift 5 AL what you need it to be.

Wheel sizes

Stability with Full 29” Wheels

M L XL

29” wheels are optimal for high speed and smooth handling, providing the best rollover capability, especially in technical sections.

Versatility with Mixed Wheels

M L XL

The mixed wheel setup, featuring a smaller 27.5” rear wheel, offers greater agility and maneuverability, while the large 29” front wheel provides excellent rollover capability and stability in rough and steep terrain.

Agility with 27.5” Wheels

S M L

Want something more playful? Ideal for riders who prefer a more nimble ride with smaller 27.5” wheels.

01_PP_Spindrift_Alu_SingleCrown-eignerframes_1159

02_PP_Spindrift_Alu_SingleCrown-eignerframes_1835

03_PP_Spindrift_Alu_SingleCrown-eignerframes_1539

04_PP_Spindrift_Alu_SingleCrown-eignerframes_1581

05_PP_Spindrift_Alu_SingleCrown-eignerframes_1671

06_PP_Spindrift_Alu_SingleCrown-eignerframes_1519

07_PP_Spindrift_Alu_SingleCrown-eignerframes_1224

Build Kits

We’re here to help you create your dream bike. Our four build kits are clear recommendations based on how we would set up our own bikes. For every riding style and budget, we provide a thoughtfully designed equipment concept that gets you “ready to ride” right out of the box. At PROPAIN, we always prioritize customization, so you can still fulfill every individual wish through our configurator.

$ 8,069

Fork:
Fox 38 Factory GripX2 180 mm
Rear shock:
Fox DHX2 Coil SLS
Drive train:
SRAM XX Eagle Transmission (1x12)
Brake:
Magura MT7 Performance 220 mm / 203 mm
Seatpost:
Fox Transfer Factory
Wheelset:
Crankbrothers Synthesis Carbon i9

$ 6,319

Fork:
RockShox ZEB Ultimate 180 mm Electric Red
Rear shock:
RockShox Vivid Air Ultimate
Drive train:
SRAM XO Eagle Transmission (1x12)
Brake:
SRAM Code RSC 220 mm / 200mm
Seatpost:
RockShox Reverb AXS incl. POD
Wheelset:
DT Swiss FR 1500

$ 5,499

Fork:
Öhlins RXF 38 180 mm
Rear shock:
Öhlins TTX 22 Coil
Drive train:
SRAM GX Eagle Transmission (1x12)
Brake:
Shimano Saint 203 mm / 203 mm
Seatpost:
OneUp Dropper V3
Wheelset:
DT Swiss EX 1700

$ 2,999

Fork:
RockShox ZEB 180 mm
Rear shock:
RockShox Vivid Coil Select R
Drive train:
SRAM GX Eagle (1x12)
Brake:
SRAM DB8 220 mm / 200 mm
Seatpost:
Sixpack Kamikaze
Wheelset:
NEWMEN Performance 30

Silence is Fast

A quiet bike changes your perception on the trail and provides a tremendous sense of security. The high-quality TPR chainstay protectors, combined with cable integration and optimized cable routing, make the Spindrift 5 AL exceptionally quiet.

Cable Ports and Internal Cable Routing

Securely screwed and internally clamped cable ports with seals to protect against dust and water ensure optimal cable management and also minimize noise. For the Spindrift 5 AL, we continue to use classic internal routing through the frame.

Bottle Mount

Every freeride adventure is demanding and unpredictable. To maintain your focus and stay hydrated even on the most remote trails, you’ll find a bottle mount on the down tube.

FREERIDE AIN’T DEAD

PRO10 and Downtube Protection

Extremely agile and balanced thanks to PRO10. Whether using a coil or air shock, this technology provides excellent anti-squat characteristics, ensuring optimal traction regardless of the setup. Our specially designed downtube protection shields the frame from external impacts and damage.

High-Quality Stainless Steel Bearings

All our installed ball bearings are made from high-quality stainless steel and are protected with double seals (PROPAIN Dirt-Shields). This makes the Spindrift 5 AL Park extremely durable and resistant.

Blend Alloy

The frame consists of at least three different alloys, which together create the optimum combination of stiffness, strength and weight. Frame parts such as rockers and axles are made of 7075 T6 aluminium, which has a very high strength. For the tubes of the frame, a more fatigue-resistant 6066 T6 aluminium is used. In addition, the milled and forged parts are made of 6061 T6 aluminium. Blend Alloy thus represents our special and unique manufacturing process and ensures the optimum performance of the lightweight frames.

Bitte leer lassen

Frame size

The size of the frame plays an important role in the bike’s performance and, above all, in its enjoyment. Select the frame size you need from the table. If you are between two sizes, then you only have to decide whether you like it playful or smooth. For smooth riding, choose the larger frame size, for playful riding, choose the smaller frame size.

S: 158-172 cm / M: 168-182 cm / L: 178-192 cm / XL: 188-202 cm
	150 cm 4’11”	160 cm 5’3″	170 cm 5’7″	180 cm 5’11”	190 cm 6’3″	200 cm 6’7″
S
M
L
XL
	Smoothly running Well-balanced Playful

Seatposts

The adjustable seatpost is probably one of the most ingenious inventions of recent years. In order to function optimally on the trail, the proper seatpost travel is very important. The following chart shows the recommended minimum inseam for the corresponding frame size. Please keep in mind that this is only a recommendation, as the respective sitting position depends very much on personal habits and preferences.

* Innenbeinlänge in cm
Spindrift 5 AL	S	M	L	XL
OneUp Dropper V3 120	73	75	77	79
OneUp Dropper V3 150	75	75	77	79
OneUp Dropper V3 180	78,5	78,5	79,5	79,5
OneUp Dropper V3 210	82	82	83	83
Bikeyoke Revive 3 125	73	75	77	79
Bikeyoke Revive 3 160	80	80	81	82,5
Bikeyoke Revive 3 185	85	85	86	86
Bikeyoke Revive 3 213	91,5	91,5	92,5	92,5
Fox Transfer Factory MY25 120	73	75	77	79
Fox Transfer Factory MY25 150	78,5	78,5	79,5	81,5
Fox Transfer Factory MY25 180	84	84	85	85
Fox Transfer Factory MY25 210	89,5	89,5	90,5	90,5
RockShox Reverb AXS 125	75,5	77,5	79,5	81,5
RockShox Reverb AXS 150	80,5	80,5	82	84
RockShox Reverb AXS 170	84,5	84,5	85,5	86

Technical Data

Shock length

230 mm

Shock travel

65 mm

Shock bushings

Top: 8 x 20 mm / Bottom: 8 x 30 mm

Travel (Frame)

180 mm

Max. Travel (Fork)

200 mm

Bottom bracket

BSA 73 mm

Brake mount (Frame)

Postmount 180

Seatpost diameter

31.6 mm

Seat clamp diameter

34.9 mm

max. Seatpost insert length

	29″ & Mix	27,5″
Frame size S	–	200 mm
Frame size M	215 mm	220 mm
Frame size L	220 mm	230 mm
Frame size XL	250 mm	–

Headset (S.H.I.S)

Top: ZS49 / Bottom: ZS56

Rear wheel axle

148 mm x 12 mm

Chainguide mount

ISCG 05

Derailleur hanger

SRAM UDH

Wheel size

29″ / Mix / 27,5″

Max. system weight

120 kg

Geometry

The Spindrift 5 AL also features our proven PRO10 System. This enhances your descents with increased agility and offers better balance on your rides. The anti-squat behavior provides improved traction and ground contact. With a slack head angle of 63.5° and an effective seat angle of 76.4°, this freerider tackles the steepest climbs with ease.

180 mm Fork

* Measured 200 mm from cener of bottom bracket
Size	S	M	L	M	L	XL	M	L	XL
Wheelsize	27,5	27,5	27,5	Mix	Mix	Mix	29	29	29
Frame height (A)	420 mm	440 mm	460 mm	440 mm	460 mm	480 mm	440 mm	460 mm	480 mm
Fork offset (B)	38 mm	38 mm	38 mm	44 mm	44 mm	44 mm	44 mm	44 mm	44 mm
Fork length (C)	577 mm	577 mm	577 mm	596 mm	596 mm	596 mm	596 mm	596 mm	596 mm
Head tube length (D)	100 mm	110 mm	120 mm	100 mm	110 mm	125 mm	100 mm	110 mm	125 mm
Reach (E)	430 mm	455 mm	478 mm	455 mm	480 mm	505 mm	455 mm	480 mm	505 mm
Stack (F)	605 mm	614 mm	623 mm	636 mm	644 mm	658 mm	636 mm	644 mm	658 mm
Head angle (G)	63,9°	63,9°	63,9°	63,9°	63,9°	63,9°	63,9°	63,9°	63,9°
Seat angle – real (H)	76,4°	76,4°	76,4°	75,2°	74,9°	74,9°	75,2°	74,9°	74,9°
Seat angle – effective (I)	78,4°	78,4°	78,4°	78,4°	78,7°	78,6°	78,4°	78,7°	78,6°
Top tube length (J)	553 mm	580 mm	607 mm	585 mm	612 mm	641 mm	585 mm	612 mm	641 mm
BB offset FW/RW (K)	R7 / F7 mm	R7 / F7 mm	R7 / F7 mm	R7 / F20 mm	R7 / F20 mm	R7 / F20 mm	R20 / F20 mm	R20 / F20 mm	R20 / F20 mm
Chainstay length (L)	435 mm	435 mm	435 mm	435 mm	435 mm	435 mm	445 mm	445 mm	445 mm
Wheelbase (M)	1.196 mm	1.226 mm	1.255 mm	1.234 mm	1.264 mm	1.295 mm	1.244 mm	1.274 mm	1.305 mm
Standover height (N)*	816 mm	814 mm	814 mm	829 mm	826 mm	829 mm	829 mm	826 mm	829 mm
BB height	342 mm	342 mm	342 mm	349 mm	349 mm	349 mm	349 mm	349 mm	349 mm

200 mm Fork

* Measured 200 mm from center of bottom bracket
	Size M	Size L	Size XL
Wheelsize	Mix only	Mix only	Mix only
Frame height (A)	440 mm	460 mm	480 mm
Fork offset (B)	52 mm	52 mm	52 mm
Fork length (C)	609 mm	609 mm	609 mm
Head tube length (D)	100 mm	110 mm	125 mm
Reach (E)	450 mm	475 mm	500 mm
Stack (F)	639 mm	647 mm	661 mm
Head angle (G)	63,5°	63,5°	63,5°
Seat angle – real (H)	74,8°	74,5°	74,5°
Seat angle – effective (I)	78°	78,3°	78,2°
Top tube length (J)	582 mm	609 mm	638 mm
BB offset FW/RW (K)	R23 / F23 mm	R23 / F23 mm	R23 / F23 mm
Chainstay length (L)	435 mm	435 mm	435 mm
Wheelbase (M)	1.248 mm	1.278 mm	1.309 mm
Standover height (N)*	832 mm	829 mm	832 mm
BB height	352 mm	352 mm	352 mm

Downloads

FAQ

You have questions about your next bike?
Our customer service team is here to help and support you!

Book an appointment now for a consultation on the phone or in our showroom. Of course, you can also contact us via our chat on our website or by email. We look forward to hearing from you!

FREERIDE AIN’T DEAD

Fork	Fox 38 Factory GripX2 180mm
Shock	Fox DHX2 Coil SLS
Brakes	Magura MT7 Performance 220mm / 203 mm
Wheels	Cranbrothers Synthesis Carbon i9 Hydra
Drivetrain	SRAM XX Eagle Transmission (1x12)
Trigger	SRAM AXS Pod Controller
Rear derailleur	SRAM XX Eagle Transmission (1x12)
Cassette	SRAM XX Eagle Transmission
Crank	SRAM XX Eagle Transmission 170 mm 32t
Handlebar	OneUp Carbon
Headset & Stem	Classic Internal / Sixpack Millenium 35
Seatpost	Fox Transfer Factory
Saddle	SQLab 6OX Infinergy ERGOWAVE
Tires	Schwalbe Magic Mary / Big Betty

Fork	RockShox ZEB Ultimate Electric Red 180 mm (only on 29"/Mix)
Shock	RockShox Vivid Air Ultimate
Brakes	SRAM Code RSC 220 mm / 200 mm
Wheels	DT Swiss FR 1500
Drive train unit	SRAM X0 Eagle Transmission (1x12)
Trigger	SRAM AXS Pod Controller
Derailleur	SRAM X0 Eagle Transmission
Cassette	SRAM X0 Eagle Transmission
Crank	SRAM X0 Eagle Transmission 170 mm 32t
Handlebar	OneUp Carbon
Headset & Stem	Sixpack Millenium 35
Seatpost	RockShox Reverb AXS incl. POD
Saddle	SQLab 6OX Infinergy
Tires	Contintental Kryptotal FR/RE 2.4 Enduro

Fork	RockShox ZEB R 180 mm
Shock	RockShox Vivid Coil Select R
Brakes	SRAM DB8 220 mm / 200 mm
Wheels	NEWMEN Performance 30
Drive train unit	SRAM GX Eagle (1x12)
Trigger	SRAM GX Eagle
Derailleur	SRAM GX Eagle
Cassette	SRAM XG-1275 Eagle
Crank	Truvative Descendant 170 mm 32t
Handlebar	Sixpack Millenium 805
Headset & Stem	Classic Internal / Sixpack Vertic
Seatpost	Sixpack Kamikaze Aluminium
Saddle	Sixpack Kamikaze
Tires	Schwalbe Magic Mary / Big Betty
