The first day of summer vacation – you and your buddy grab your bikes and go. Build kickers, explore the woods behind your house and just have fun. The whole day on the bike. That’s what the Yuma 3 is made for.
Bike park approved – The Yuma 3 is classified category 5 and therefore does not fear rough terrain and big jumps. Robustly built to withstand even the hardest rides!
From 1.25m it’s good to go. Thanks to the reduced standover height the Yuma 3 is easy to handle. The kinematics are specially designed so that the suspension works well even with light weight riders.
Everyone grows up and progresses and so does the Yuma 3, it can grow with you. Our “rookie launcher” comes with 24″ wheels. With a flip chip, the bike can be converted to 26″ wheels in the blink of an eye. So, the bike grows with you and lasts a long time.
The Grown-Up Kit on 26″ wheels can be purchased in our web shop and is not included with the bike.
Components specially selected for the needs of kids round off the Yuma 3 as a proper mountain bike for young and ambitious riders. Make the world as you like it: As with all PROPAIN bikes, you can freely combine the frame color with decals and grips.
RockShox Deluxe Select R 140mm
SRAM Guide T 200mm / 180mm
Newmen Evolution X.A.25
The suspension system of the Yuma 3 is ideally designed for kids and their needs. It is very light and at the same time provides the optimum sensitivity and progression. In addition, it is easy to maintain and simple to handle.
A tool, snacks or spare tube – a practical storage bag for all the important little things on the next trail ride.
The Yuma 3 is equipped for any challenge thanks to the superior shifting performance of the 1×11 SRAM GX drivetrain. Even steep ramps can be climbed easily. The frame is protected by our chainstay protector for those times when you really hit it.
The Yuma 3 may be small, but it doesn’t lag behind the big sibling bikes and therefore comes with many thoughtful details.
14″: 90-110 cm / 16″: 95-115 cm / 20″: 110-145 cm / 24″: 130-145 cm / 26″: 145-160 cm
|90 cm||100 cm||110 cm||120 cm||130 cm||140 cm||150 cm|
|Shock length||185 mm|
|Shock travel||55 mm|
|Shock bushings||Top: Trunnion / Bottom: 8 x 35 mm|
|Travel (Frame)||140 mm|
|Max. Travel (Fork)||150 mm|
|Bottom Bracket BSA||73 mm|
|Brake mount (Frame)||Postmount 160|
|Seatpost diameter||31,6 mm|
|max. Seatpost insert length||300 mm|
|Headset (S.H.I.S.)||Top: IS42 / Bottom: IS52|
|Rear wheel axle||148 mm x 12 mm|
|Chainline Offset||3 mm Offset|
|Chainline||52 mm (Boost)|
|Chainguide mount||ISCG 05|
|Derailleur hanger||PROPAIN Yuma Derailleur hanger|
|Wheel sizes||24″ / 26″|
|Frame weight||2,7 kg|
|Max. rider weight||80 kg|
|Frame height (A)||320 mm||320 mm|
|Fork offset (B)||42 mm||42 mm|
|Fork length (C)||520 mm||520 mm|
|Head tube length (D)||95 mm||95 mm|
|Reach (E)||380 mm||380 mm|
|Stack (F)||545 mm||545 mm|
|Head angle (G)||65°||65°|
|Seat angle – real (H)||72.5°||72.5°|
|Seat angle – effective (I)||75°||75°|
|Top tube length (J)||526 mm||526 mm|
|BB offset (K)||3 mm||3 mm|
|Chainstay length (L)||420 mm||432 mm|
|Wheelbase (M)||1,099 mm||1,111 mm|
|Standover height (N)*||662 mm||687 mm|
Frequently Asked Questions – bitte leer lassen
The Yuma has cable channels prepared inside the frame for the cable routing of a dropper seat post. Therefore, dropper seat posts can be retrofitted if required.
The bike comes with all the instructions and manuals you need.
