What does gravel mean to you? Long rides off-road or technical challenges in the woods? Multi-day bikepacking trips or long-distance gravel competitions? We’ve developed the Terrel CF around the versatility of this discipline, and it comes with a powerful ace up its sleeve – the PROPAIN configurator.
The Terrel allows you to tailor it to a wide range of applications. Whether it’s a carbon fork and an aero wheelset for maximum efficiency and speed, or a suspension fork and a dropper post for ultimate comfort and trail performance. Whether it’s a 2x drivetrain for tight gear steps or a transmission derailleur and cassette for extreme range and quick shifting under load.
Make the Terrel what you need it to be.
Included in delivery:
Day trip, weekend getaway, or bikepacking adventure beyond borders. Pack your gear onto the robustly configured Terrel and enjoy worry-free long days in the saddle for lasting memories.
With a dropper post and suspension fork, you have full control and freedom of movement to really push the Terrel in rough terrain.
Lightweight yet built tough, the Terrel is absolutely “ready to race” thanks to its high torsional rigidity and progressive geometry. Challenge yourself and your competition
The frame geometry is fully “suspension-corrected,” meaning it has been designed for use with a 40mm travel suspension fork. Our rigid carbon fork has the same axle-to-crown height, ensuring that it does not alter the geometry.
To ensure you’re fully equipped for bikepacking and commuting, the ability to store equipment on the bike is extremely important. With mounting points for frame bags and top tube bags on the top tube, mounting points for bags or cages on the fork sides, and mounting points for fenders and racks, as well as three bottle cages, we’ve covered all the bases with the Terrel. With our mounting points for all your equipment, you achieve a clean look without the hassle of straps. Your gear always stays exactly where it should, without wobbling, rattling, rubbing, or slipping.
A frame bag that can always stay on the bike. The sleek, size-specific bag fits perfectly into the triangle of the Terrel frame. It is fixed tool-free at the screw points, allowing it to seamlessly integrate into the design, and can thus remain on the bike unnoticed. And if you ever need to carry more, you can easily expand the volume of the bag from 3,5l to 5l with the full-length zipper.
Our Wilderness Essential Equipment Depository Box allows you to store all your essential gear within the frame through a large opening in the downtube. With our uniquely developed closure system, it’s easy to open even when a bottle is attached. It’s sealed against dust, mud, and water, and doesn’t rattle. With the two included bags, the Tube Bag and the Tool Bag, you can store not only the titular utensils but also keys, valuables, and anything else you need to stow away in smaller compartments.
A soft TPR protector shields the chainstays of the Terrel. The added bumps efficiently dampen chain vibrations, ensuring absolute silence even when riding trails with the Terrel. The downtube protection guards the Blend Carbon frame against rock strikes and ground contact while also providing the option to mount a third water bottle.
The threaded T47 bottom bracket with its large, durable bearings requires minimal maintenance. Unlike press-fit bottom brackets, it tend to develop noises. Once installed, you can ride worry-free. The UDH dropout is easy to replace in case of damage and allows for the installation of SRAM transmission derailleurs.
A soft TPR protector shields the chainstays of the Terrel. The added bumps efficiently dampen chain vibrations, ensuring absolute silence even when riding trails with the Terrel. The downtube protection guards the Blend Carbon frame against rock strikes and ground contact while also providing the option to mount a third water bottle.
For a modern carbon frame that can withstand ambitious riding for a long time, it is not enough to just use a good carbon material. Instead, it requires a mixture of different carbon fibers and fabrics and their diverse properties to meet the requirements. PROPAIN carbon frames are made from pre-impregnated (prepreg) carbon layers. These guarantee an optimal resin content and ensure significantly higher strength values. Each of the layers has special properties and corresponding tasks in certain parts of the frame. Based on the requirements for stiffness, flexibility, impact resistance, weight, strength and the direction of tension, different fibers and fabrics are used. In our Terrel, we deliberately use an additional high-quality high modulus fiber, which allows us to make the frame extremely stiff against torsion when starting, without having to make any compromises in terms of vibration damping and seating comfort.
Bitte leer lassen
| 150 cm 4’11” | 160 cm 5’3″ | 170 cm 5’7″ | 180 cm 5’11” | 190 cm 6’3″ | 200 cm 6’7″ | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| XS |
|
||||||||||
| S |
|
||||||||||
| M |
|
||||||||||
| L |
|
||||||||||
| XL |
|
||||||||||
| SRESH CF | Größe S | Größe M | Größe L | Größe XL |
|---|---|---|---|---|
| OneUp Dropper V3 120 | 71 | 72,5 | 75 | 77,5 |
| OneUp Dropper V3 150 | 74,5 | 75,5 | 78 | 80,5 |
| OneUp Dropper V3 180 | 80,5 | 80,5 | 81 | 83,5 |
| OneUp Dropper V3 210 | 87 | 87 | 87,5 | 88 |
| Bikeyoke Revive 125 | 72,5 | 74 | 76,5 | 79 |
| Bikeyoke Revive 160 | 77,5 | 77,5 | 80 | 82,5 |
| Bikeyoke Revive 185 | 82,5 | 82,5 | 83 | 85 |
| Bikeyoke Revive 213 | 89 | 89 | 89,5 | 90 |
| Fox Transfer 125 | 72 | 74 | 76,5 | 79 |
| Fox Transfer 150 | 76 | 76,5 | 79 | 81,5 |
| Fox Transfer 175 | 81,5 | 81,5 | 82 | 84 |
| Fox Transfer 200 | 87 | 87 | 87,5 | 88,5 |
| RockShox Reverb AXS 125 | 75 | 76,5 | 79 | 81,5 |
| RockShox Reverb AXS 150 | 78,5 | 79 | 81,5 | 84 |
| RockShox Reverb AXS 170 | 82 | 82 | 83,5 | 86 |
| Wheel size | 700C |
| Max. tire clearance | 50 mm |
| Max. travel (Fork) | 40 mm |
| Bottom bracket | T47 |
| Brake mount (Frame) | Flatmount 160 direct |
| Seatpost diameter | 27.2 mm |
| Seatclamp diameter | 31.8 mm |
| Headset (S.H.I.S) | IS52/IS52 |
| Rear wheel axle | 142 mm |
| Derailleur front | Braze-on |
| Derailleur hanger | UDH |
| Max. system weight | 130 kg |
| Max. weight mounting points |
Fork: 3 kg per side, no low ride type racks Rear: 8 kg per side, total max. of 16 kg on the rear triangle Frame: behind the stem max. 3 kg |
| SIZE XS | SIZE S | SIZE M | SIZE L | SIZE XL | |
|---|---|---|---|---|---|
| Frame height (A) | 470 mm | 510 mm | 525 mm | 545 mm | 570 mm |
| Fork offset (B) | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Fork length (C) | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Head tube length (D) | 98 mm | 116 mm | 130 mm | 154 mm | 177 mm |
| Reach (E) | 382 mm | 396 mm | 405 mm | 412 mm | 430 mm |
| Stack (F) | 554 mm | 568 mm | 583 mm | 608 mm | 632 mm |
| Head angle (G) | 69.5° | 70° | 70.5° | 71° | 71.5° |
| Seat angle (H) | 74.3° | 73.5° | 73.5° | 73.5° | 73.5° |
| Top tube length (I) | 538 mm | 564 mm | 578 mm | 592 mm | 617 mm |
| BB offset (J) | 77 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| BB height (K) | 287 mm | 292 mm | 292 mm | 292 mm | 292 mm |
| Chainstay length (L) | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase (M) | 1,037 mm | 1,053 mm | 1,062 mm | 1,073 mm | 1,094 mm |
| Standover height (N)* | 787 mm | 803 mm | 820 mm | 843 mm | 862 mm |
