Original price was: USD $7,299.00.USD $5,999.00Current price is: USD $5,999.00.
Out of stock
Hugene is our interpretation of the perfect trailbike. A bike that flies up mountains with ease and puts a fat smile on your face on the way back down. For the first time, we are relying on large 29″ wheels and have optimized our proven PRO10 suspension system for them. This results in a great balance between stability and playfulness, providing lots of safety for the rider without feeling boring. The shock sits in front of the seatpost and is perfectly protected against dirt and mud. To make the Hugene a agile trailbike, we’ve paid particular attention to its drive efficiency. Providing 100% anti-squat, the chainstay always keeps its cool on the uphills. The Hugene climbs almost like a hardtail but also offers sturdy downhill performance due to its progressive suspension kinematics that have been optimized offering both perfect sensitivity and bottom out resistance.
We help you on the way to your personal dream bike. In our configuration tool you can customize your bike by choosing coloured decals, grips and saddles.
The frame size is an essential part of the bike performance and above all of the riding fun. Select your required frame size from the table. If you stand between two sizes, then you only have to decide whether you like it playful or smooth running. For smooth running choose the larger frame size, for playful the smaller.
The adjustable seat post is probably one of the most ingenious inventions of recent years. In order for it to function optimally on the trail, the proper seatpost travel is very important. The following table shows the recommended minimum inseam for the corresponding frame size. Please keep in mind that this is only a recommendation, as the respective sitting position depends very much on personal habits and preferences.
| HUGENE | S | M | L | XL |
|---|---|---|---|---|
| Bikeyoke Revive 125 | 72,5 | 75,5 | 78,5 | 81,5 |
| Kind Shock Lev 125 | 73,5 | 76,5 | 79,5 | 82,5 |
| Fox Transfer 125 | 74,5 | 77,5 | 80,5 | 83,5 |
| Bikeyoke Revive 160 / Kind Shock Lev 150 | 76,0 | 79,0 | 82,0 | 85,0 |
| Fox Transfer 150 | 77,0 | 80,0 | 83,0 | 86,0 |
| Shock length | 190 mm |
| Shock travel | 45 mm |
| Shock mount | 8 x 30 mm |
| Rear wheel travel | 130 mm |
| Bottom bracket BSA | 73 mm |
| Brake mount | Postmount 180 |
| Seatpost diameter | 31,6 mm |
| Headset (S.H.I.S) | Tapered - Top: IS42 / Bottom: IS52 |
| Rear wheel axle | 148 mm x 12 mm (X12) |
| Front derailleur | none |
| Chainline | 52 mm (Boost) |
| Chainguide mount | none |
| Wheel size | 29" |
| Maximum fork travel | 150 mm |
| Frame weight | 2,4 kg (Size M) |
| SIZE S | SIZE M | SIZE L | SIZE XL | |
|---|---|---|---|---|
| Frame height (A) | 410 mm / 16,5″ | 440 mm / 17,5″ | 470 mm / 18,5″ | 500 mm / 19,5″ |
| Wheelbase (M) | 1.146 mm | 1.175 mm | 1.204 mm | 1.232 mm |
| Top tube length (J) | 571 mm | 599 mm | 626 mm | 654 mm |
| Fork offset (B) | 51 mm | 51 mm | 51 mm | 51 mm |
| Fork length (C) | 546 mm | 546 mm | 546 mm | 546 mm |
| Chainstay length (L) | 445 mm | 445 mm | 445 mm | 445 mm |
| Reach (E) | 410 mm | 435 mm | 460 mm | 485 mm |
| Stack (F) | 602 mm | 612 mm | 621 mm | 630 mm |
| Head angle (G) | 67,5° | 67,5° | 67,5° | 67,5° |
| Seat angle – real (H) | 71° | 71° | 71° | 71° |
| Seat angle – effective (I) | 75° | 75° | 75° | 75° |
| Head tube length (D) | 95 mm | 105 mm | 115 mm | 125 mm |
| BB offset (K) | 30 mm | 30 mm | 30 mm | 30 mm |
| SIZE S | SIZE M | SIZE L | SIZE XL | |
|---|---|---|---|---|
| Frame height (A) | 410 mm / 16,5″ | 440 mm / 17,5″ | 470 mm / 18,5″ | 500 mm / 19,5″ |
| Wheelbase (M) | 1.150 mm | 1.179 mm | 1.208 mm | 1.236 mm |
| Top tube length (J) | 573 mm | 601 mm | 628 mm | 656 mm |
| Fork offset (B) | 51 mm | 51 mm | 51 mm | 51 mm |
| Fork length (C) | 556 mm | 556 mm | 556 mm | 556 mm |
| Chainstay length (L) | 445 mm | 445 mm | 445 mm | 445 mm |
| Reach (E) | 407 mm | 432mm | 457 mm | 482 mm |
| Stack (F) | 605 mm | 615 mm | 624 mm | 633 mm |
| Head angle (G) | 67,0° | 67,0° | 67,0° | 67,0° |
| Seat angle – real (H) | 70,5° | 70,5° | 70,5° | 70,5° |
| Seat angle – effective (I) | 74,5° | 74,5° | 74,5° | 74,5° |
| Head tube length (D) | 95 mm | 105 mm | 115 mm | 125 mm |
| BB offset (K) | 28 mm | 28 mm | 28 mm | 28 mm |
