Tour, trail, all-mountain? Take your pick, the new Hugene does it all. With 140 mm of rear travel and a choice of 140 or 150 mm in the front, this is a bike that always delivers. Whether it’s a brisk trail ride, an all-day tour, or traversing the alps, the Hugene makes you a summiteer on every climb and a rocket on the descents.
The lightweight Blend Carbon frame paired with 29″ wheels will efficiently get you up even the steepest climbs. On descents, perfectly tuned 140 mm travel in our "Trail-Tuned" PRO10 frame and a choice of 140 or 150 mm travel at the front give you total control and playful handling. With the combination of confident stability, an effective suspension system that generates an extremely high level of grip for its class and agile handling, you can pop off every root and get maximum fun out of every trail on any terrain.
Do you like steep climbs and long uphill sections? Thanks to the steep seat angle, spacious reach and high anti-squat of the PRO10 frame, our Hugene climbs smoothly and effectively. Your power is transferred directly to the ground without bobbing, even with the shock open, and the riding position is optimized so that a raising front wheel is a thing of the past. The 29″ wheels provide plenty of drive and traction to get you to your destination.
Do you crave flow wherever you ride, even on technical terrain? No problem with our Hugene. The large wheels guarantee stability and excellent roll-over behavior. Thanks to the modern but moderate geometry with a head angle of 65.5°, the Hugene is also very agile, and the poppy ride feel lets you fly playfully from turn to turn.
Are you looking for a trail bike that allows you to efficiently tackle even the longest tours, doesn't shy away from rough sections, and playfully gets the most fun out of every trail? Then the Hugene is exactly the right choice for you!
We at PROPAIN always remain committed to custom, so you can still fulfill your every individual wish in our configurator. Still, we want to help guide you on the way to your personal dream bike. Our three build kits are confidently recommended, because we would build our own bikes exactly the same way. For every use case and every budget, we provide you with a well-thought-out spec concept, each of which is fully “ready to shred”.
Good looks aren't everything. Our Hugene also impresses with its core values and smart detail solutions. With a sophisticated frame concept, our award-winning PRO10 system, durable bearings, internal cable routing and an efficient chainstay protector, you can enjoy your ride with complete peace of mind.
On our Hugene, we manufacture the upper link of the PRO10 system from carbon to optimize the weight of the frame. This also allows for the link to be painted in the frame color and rounds off the design.
Cable ducts run through the frame of our Hugene 2, which not only protect the cables from dirt and eliminate annoying rattling, but also make cable routing very easy.
The robust Acros frame bearings are additionally protected by our PROPAIN dirt shields. An extra seal protects the underlying bearings from dust, water, and dirt.
To keep your frame protected at all times, our Hugene 2 comes with a custom chainstay and downtube protectors. The chainstay protector absorbs chain vibrations and minimizes noise.
A good trail bike of course needs the ability to carry enough hydration and the most necessary equipment for a long day on the bike. The less weight in the backpack or hip bag the better. The bottle mount on the down tube and the tool mount on the bottom of the top tube provide the perfect platform for this.
Whether pedaling uphill or going down fast, our Hugene 2 always keeps a cool head. And off the trail it’s just a natural beauty.
We are convinced that it is not enough to just use one good carbon material for a frame. Instead, it needs different carbon materials and their diverse properties to meet the requirements. PROPAIN carbon frames are made from pre-impregnated (prepreg) carbon layers. These guarantee an optimum resin content and thus ensure significantly higher strength values. Each of the layers has special properties and corresponding tasks at specific points of the frame. Based on the requirements for stiffness, flexibility, impact resistance, weight, strength and the direction of stress, different fibers and fabrics are used. PROPAIN uses only the highest quality materials. For example, the carbon fibers used in our frames are the same as those used in the latest generation of aviation components.
| 150cm 4'11“ | 160cm 5'3″ | 170cm 5'7″ | 180cm 5'11“ | 190cm 6'3″ | 200cm 6'7″ | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| S |
|
||||||||||
| M |
|
||||||||||
| L |
|
||||||||||
| XL |
|
||||||||||
|
|
|||||||||||
The adjustable seatpost is probably one of the most ingenious inventions of recent years. In order to function optimally on the trail, the proper seatpost travel is very important. The following chart shows the recommended minimum inseam for the corresponding frame size. Please keep in mind that this is only a recommendation, as the respective sitting position depends very much on personal habits and preferences.
| HUGE CF | S | M | L | XL |
|---|---|---|---|---|
| Bikeyoke Divine 125 | 72 | 74 | 77 | 80 |
| Bikeyoke Divine 160 | 75 | 78 | 80 | 83 |
| Bikeyoke Divine 185 | 80 | 80,5 | 83 | 86 |
| Bikeyoke Revive 125 | 72 | 74 | 77 | 80 |
| Bikeyoke Revive 160 | 75 | 78 | 80 | 83 |
| Bikeyoke Revive 185 | 80 | 80,5 | 83 | 86 |
| Bikeyoke Revive 3 125 | 70,5 | 73 | 75,5 | 78,5 |
| Bikeyoke Revive 3 160 | 75,5 | 76,5 | 79 | 82 |
| Bikeyoke Revive 3 185 | 80,5 | 80,5 | 81,5 | 84,5 |
| Bikeyoke Revive 3 213 | 87 | 87 | 88 | 90,5 |
| Fox 125 | 73,5 | 76 | 78,5 | 81,5 |
| Fox Transfer 150 | 77 | 78,5 | 81 | 84 |
| Fox Transfer 175 | 82 | 82,5 | 83,5 | 86,5 |
| RockShox Reverb AXS 125 | 74 | 76,5 | 79 | 82 |
| RockShox Reverb AXS150 | 76,5 | 79 | 81,5 | 84,5 |
| RockShox Reverb AXS170 | 79,5 | 82 | 84,5 | 87,5 |
| Shock length | 210mm |
| Shock travel | 50mm |
| Shock bushings | 8x30mm |
| Travel (Frame) | 140mm |
| Max. Travel (Fork) | 150mm |
| Bottom bracket BSA | 73mm |
| Brake mount (Frame) | Postmount 180 |
| Seatpost diameter | 31.6mm |
| Seatclamp diameter | 34.9mm |
| max. Seatpost insert length | S 220mm / M 245mm / L 260mm / XL 265mm |
| Headset (S.H.I.S.) | Top: IS42 / Bottom: IS52 |
| Rear wheel axle | 148mm x 12mm |
| Chainline Offset | 3mm offset |
| Chainline | 52mm (Boost) |
| Chainguide mount | ISCG 05 |
| Derailleur hanger | SRAM UD |
| Wheel size | 29″ |
| Frame weight | 2.3kg |
| Max. system weight | 120kg |
By combining a flat steering angle of 65.5° with a steep seat angle of 76.5° (effective) and the floating shock, which is centrally mounted in the bike, we achieve exactly this: easy pedalling on the uphill with a lot of pressure on the front wheel and an optimal weight distribution on the downhill. A characteristic that you notice once you get on the bike and never want to miss again afterwards. Remarkably, this geometry change has significantly improved both the uphill and downhill performance. A reach of 476 mm with a chainstay length of 445 mm at size L makes the new Hugene smoother and more agile than before and creates a noticeable balance.
| Sise S | Size M | Size L | Size XL | |
|---|---|---|---|---|
| Frame height (A) | 400mm | 425mm | 450mm | 480mm |
| Fork offset (B) | 42mm | 42mm | 42mm | 42mm |
| Fork length (C) | 555mm | 555mm | 555mm | 555mm |
| Head tube length (D) | 100mm | 110mm | 120mm | 130mm |
| Reach (E) | 430mm | 455mm | 480mm | 505mm |
| Stack (F) | 612mm | 621mm | 630mm | 640mm |
| Head angle (G) | 65.5° | 65.5° | 65.5° | 65.5° |
| Seat angle – real (H) | 73.1° | 73.1° | 73.1° | 73.1° |
| Seat angle – effective (I) | 76.5° | 76.5° | 76.5° | 76.5° |
| Top tube length (J) | 577mm | 604mm | 631mm | 659mm |
| BB offset (K) | 34mm | 34mm | 34mm | 34mm |
| Chainstay length (L) | 445mm | 445mm | 445mm | 445mm |
| Wheelbase (M) | 1,184mm | 1,213mm | 1,242mm | 1,271mm |
| BB height | 342mm | 342mm | 342mm | 342mm |
| Sise S | Size M | Size L | Size XL | |
|---|---|---|---|---|
| Frame height (A) | 400mm | 425mm | 450mm | 480mm |
| Fork offset (B) | 42mm | 42mm | 42mm | 42mm |
| Fork length (C) | 565mm | 565mm | 565mm | 565mm |
| Head tube length (D) | 100mm | 110mm | 120mm | 130mm |
| Reach (E) | 426mm | 451mm | 476mm | 501mm |
| Stack (F) | 616mm | 625mm | 634mm | 644mm |
| Head angle (G) | 65.1° | 65.1° | 65.1° | 65.1° |
| Seat angle – real (H) | 72.7° | 72.7° | 72.7° | 72.7° |
| Seat angle – effective (I) | 76.1° | 76.1° | 76.1° | 76.1° |
| Top tube length (J) | 578mm | 605mm | 632mm | 660mm |
| BB offset (K) | 30mm | 30mm | 30mm | 30mm |
| Chainstay length (L) | 445mm | 445mm | 445mm | 445mm |
| Wheelbase (M) | 1,188mm | 1,217mm | 1,246mm | 1,275mm |
| BB height | 346mm | 346mm | 346mm | 346mm |
Can I use the Hugene in bike parks?
Our Hugene is assigned to bike category 4. Regular and permanent use on North Shore trails and in bike parks should therefore be avoided. Use in rough terrain and moderate jumps are no problem. After intense use, you should check your bike for damage before and after each ride.
Can I ride a 27.5″ wheel on the rear of the Hugene?
Due to its geometry and frame characteristics, the Hugene is only designed for the use of 29″ wheels. Therefore it is not possible to mount wheels in 27.5″.
Why is the Hugene not available in 27.5″?
With its 29″ wheels, our trail bike is your ideal companion for longer tours or for your local home trails. The large wheels ensure optimal climbing characteristics in the uphill as well as solid performance over sticks and stones in the downhill. We are therefore convinced that 29″ wheels are the better choice for this field of use.
What is the frame mount below the top tube for?
The mount is used to fix straps, tools, tubes or other spare parts that could be helpful on your tour.
Which bottle size fits in the frame?
Attaching drinking bottles up to 0.5 l is no problem. With larger frame sizes, 0.7 l bottles can also be stowed.
What does the delivery include?
The bike comes with three stem spacers, uncut handlebars and all the instructions you need.
We offer further equipment like pedals in our online store.
What is the maximum tire width that fits the frame?
A general statement is not possible here due to the tolerances of the tire manufacturers’ width specifications.
E.g. fit Schwalbe tires up to 2.4, VEE up to 2.35 and Maxxis up to 2.5WT.
How much does the Hugene weigh in my build?
Due to the large selection of components and frame sizes, we cannot make a statement for all combinations. However, we have given weights for our build kits, which you can see in the table above. In the configurator you will also find weight information for each component.
Do you also offer other components that are not listed in the configurator?
No, we only offer the components and color variants that we show in the configurator.
What does my frame look like in the colour Raw?
Carbon raw is a real beauty! The frames are getting a special treatment before we paint them so the carbon surface, which is shining through the paint, is showing its best side. Besides the clear paint there is also a light dark coating applied. This results in a light dark shine of carbon material, especially in sunlight. Each model is different so every method and also materials will differ. That also means every single frame is a unique.
15,00 €
VAT included., plus shipping
Ursprünglicher Preis war: 59,95 €50,00 €Aktueller Preis ist: 50,00 €.
VAT included., plus shipping
Ursprünglicher Preis war: 89,95 €75,00 €Aktueller Preis ist: 75,00 €.
VAT included., plus shippingBecome part of the PROPAIN community and receive all updates about our products, athletes and insights with our newsletter.
© 2024 Propain Bicycles GmbH
Not only is this equipment an absolute eye-catcher, but it also impresses with an outstanding technical performance. The combination of the high-end suspension fork and shock sets standards for a smooth riding experience. Magura MT7 and SRAM X01 ensure maximum precision and performance.
| Fork | Fox 36 Factory Kashima |
|---|---|
| Shock | Fox Float X Factory Kashima |
| Brakes | Magura MT7 203mm / 203mm |
| Wheels | Newmen Advance SL.A 30 |
| Drive train unit | SRAM X0 Transmission |
| Trigger | SRAM AXS Pod Controller |
| Derailleur | SRAM X0 Eagle Transmission (1x12) |
| Cassette | SRAM X0 Eagle Transmission |
| Crank | SRAM X0 Eagle Transmission 170 mm 32T |
| Handlebar | SIXPACK Millenium 805 20 mm rise |
| Headset & Stem | SIXPACK Millenium 35 |
| Seatpost | Fox Transfer Factory Kashima |
| Saddle | SQLab 6OX Infinergy ERGOWAVE |
| Tires | Schwalbe Magic Mary / Big Betty |
The Rockshox Ultimate RC suspension not only offers style, but also functionality and user-friendliness to the highest degree. The NEWMEN Beskar 30 Base wheels and the GX Eagle drive from SRAM get the whole thing rolling.
| Fork | RockShox Lyrik Ultimate |
|---|---|
| Shock | RockShox Super Deluxe Ultimate |
| Brakes | SRAM Code RSC |
| Wheels | NEWMEN Beskar 30 Base |
| Drive train unit | SRAM GX Transmission |
| Trigger | SRAM AXS Pod Controller |
| Derailleur | SRAM GX Eagle Transmission (1x12) |
| Cassette | SRAM GX Eagle Transmission |
| Crank | SRAM GX Eagle Transmission 170 mm 32T |
| Handlebar | SIXPACK Millenium 805 20 mm rise |
| Headset & Stem | SIXPACK Millenium 35 |
| Seatpost | BikeYoke Revive |
| Saddle | SIXPACK Kamikaze |
| Tires | Schwalbe Magic Mary / Big Betty |
The ideal solution for riders who value efficiency as well as affordability. The basic equipment comes with top components, providing a cost-effective bundle perfect for the beginning of a mountainbike carrer. Featuring the RockShox Pike Select, the Select + shock and the SRAM G2 R brakes, this version offers a solid base.
| Fork | RockShox Pike Select |
|---|---|
| Shock | RockShox Select + |
| Brakes | SRAM G2 R 200mm / 200mm |
| Wheels | NEWMEN Performance 30 Base |
| Drive train unit | SRAM GX Eagle |
| Trigger | SRAM GX Eagle (1x12) |
| Derailleur | SRAM GX Eagle (1x12) |
| Cassette | SRAM XG1275 10-52 |
| Crank | TRUVATIV Descendant Alu 170 mm 32T |
| Handlebar | SIXPACK Millenium 805 20 mm rise |
| Headset & Stem | SIXPACK Vertic 50 |
| Seatpost | OneUp Dropper V3 |
| Saddle | SIXPACK Kamikaze |
| Tires | Schwalbe Nobby Nic |
